Evaluation unit NLSW45-4 with relay output for monitoring the flow of liquids

SKU: 74297

Description

Flow monitor for monitoring liquids

With switching output (1 NO/ 1 NC) suitable for control cabinet installation, robust stainless steel sensor housings for industrial environments available separately

Large measuring range for flow monitoring of liquids (0.03 ... 3 m/s) and gases (0.5 ... 20 m/s)

Type tested by TÜV NORD in accordance with DIN EN 61010-1: 2011-07

Sensitive and infinitely adjustable switching point

Example areas of application: Monitoring of air and water flows, cooling circuits up to 30% glycol content, pump monitoring

Operating voltage
€170,70
Shipping will be charged at checkout.

Operating instructions EN: Download

Operating instructions EN: Download

Specification
  • Medium
    Liquids, gases
  • Device type
    Flow evaluation unit for switch cabinet installation
  • Flow measuring range
    Air: 0.5 ... 20 m/s, Water: 0.05 ... 3 m/s
  • Media temperature
    -15 ... 80°C
  • Display
    LED (voltage & switching point)
  • Switching point
    Stepless adjustment (potentiometer)
  • Protection class evaluation unit
    IP40
  • Special features
    closed probe
  • Output signal
    Switching output
  • Switching output specification
    1 changer
  • Signal output sensor break
    Relay drops out
  • Signal output Sensor short circuit
    Relay drops out
  • Relay output specification
    1 changer
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Weight
    190 g
  • Housing dimensions
    120 mm x 45 mm x 73 mm
  • Assembly
    DIN rail
  • Power supply
    24 V AC/DC ± 5%, 230 V AC ± 6%
  • Electrical connection
    Terminal strip
  • Power consumption max
    3 VA
  • Recommended cable cross-section
    2.5 mm²
  • Current and contact load capacity
    250 VAC, 8 A, 2 kVA
  • Minimum switching capacity
    10 mA/ 5 V DC
  • Ambient temperature
    -20 ... 50°C
  • Certificates
    CE, Type-tested TÜV Nord according to DIN EN 61010-1 2011-07
  • Country of origin
    Germany
  • Customs tariff number
    90 26 80 20
  • HS Code
    90 26 80

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Evaluation unit NLSW45-4 with relay output for monitoring the flow of liquids

€170,70

Flow monitor for monitoring liquids

With switching output (1 NO/ 1 NC) suitable for control cabinet installation, robust stainless steel sensor housings for industrial environments available separately

Large measuring range for flow monitoring of liquids (0.03 ... 3 m/s) and gases (0.5 ... 20 m/s)

Type tested by TÜV NORD in accordance with DIN EN 61010-1: 2011-07

Sensitive and infinitely adjustable switching point

Example areas of application: Monitoring of air and water flows, cooling circuits up to 30% glycol content, pump monitoring
