Evaluation unit NLSW45-3 Ex, flow monitoring for ATEX areas

SKU: 63377Ex

Description

✅ Luftstromwächter für Überwachung von Luftströmung in ATEX-Zonen 1 und 2 (optional zusätzlich mit SIL1- oder SIL2-Zertifizierung)

✅ Mit Schaltausgang (1 NO/ 1 NC) für Schaltschrankeinbau

✅ Type tested by TÜV NORD in accordance with DIN EN 61010-1: 2011-07

✅ Großer Messbereich (0,1 … 30 m/s), einfache und schnelle Inbetriebnahme

✅ Beispiel Einsatzbereiche: Überwachung Heizregister, Luftschleieranlagen, Stellklappen, Ventilatoren, DDC, Industrieöfen, Granulattrockner

Operating voltage
€548,00
Shipping will be charged at checkout.

Operating instructions EN: Download

Operating instructions EN: Download

Specification

  • Medium
    Gases
  • Device type
    Flow evaluation unit for switch cabinet installation
  • Flow measuring range
    0.1 ... 20 m/s
  • Media temperature
    0 ... 60°C
  • Display
    LED (voltage & switching point)
  • Switching point
    Stepless adjustment (potentiometer)
  • Protection class evaluation unit
    IP40
  • Special features
    2 Zener barriers included in the scope of delivery , Start-up override 5-60 sec, Additional external start-up override
  • Output signal
    Switching output
  • Switching output specification
    1 changer
  • Signal output sensor break
    Relay drops out
  • Signal output Sensor short circuit
    Relay drops out
  • Relay output specification
    1 changer
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing dimensions
    120 mm x 45 mm x 73 mm
  • Assembly
    DIN rail, to be mounted outside the ATEX zone
  • Power supply
    24 V DC ±5%, 24 V AC ±5%, 230 V AC ±5%
  • Electrical connection
    Terminal strip
  • Power consumption max
    3 VA
  • Recommended cable cross-section
    2.5 mm²
  • Current and contact load capacity
    250 VAC, 8 A, 2 kVA
  • Minimum switching capacity
    10 mA, 5 V DC
  • Ambient temperature
    -20 ... 50°C
  • Certificates
    CE, Type-tested TÜV Nord according to DIN EN 61010-1 2011-07
  • ATEX certification
    Zone 1, zone 2
  • Country of origin
    Germany
  • Customs tariff number
    90 26 80 20
  • HS Code
    90 26 80
