Evaluation unit NLSW45-3 Ex SIL1, flow monitoring for ATEX areas with SIL1 certification
Description
Description
Flow monitoring with SIL1 certification in accordance with IEC 62061 (corresponds to performance level c in accordance with EN ISO 13849-1)
Can be used in ATEX zones 1 and 2 in conjunction with the 2 Zener barriers supplied
Wide measuring range from 0.1 to 30 m/s with media temperatures from 0°C to 60°C
With switching output suitable for switch cabinet installation
Developed for demanding industrial applications, IP40
Exemplary areas of application: Flow monitoring in paint shops, paper mills and research facilities
Evaluation unit NLSW45-3 Ex SIL1, flow monitoring for ATEX areas with SIL1 certification - 230 V AC is in stock and will be shipped as soon as it is available again
Availability for pickups could not be loaded
Specification
Specification
-
MediumGases
-
Device typeFlow evaluation unit for switch cabinet installation
-
Flow measuring range0.1 ... 20 m/s
-
Media temperature0 ... 60°C
-
DisplayLED (voltage & switching point)
-
Switching pointStepless adjustment (potentiometer)
-
Protection class evaluation unitIP40
-
Special features2 Zener barriers included in the scope of delivery Start-up override 5-60 sec., additional external start-up override
-
Switching output specification1 changer
-
Signal output sensor breakRelay drops out
-
Signal output Sensor short circuitRelay drops out
-
Relay output specification1 changer
-
Housing materialPolycarbonate glass fiber reinforced (UL94V-0)
-
Housing materialPolycarbonate glass fiber reinforced (UL94V-0)
-
Housing dimensions120 mm x 45 mm x 73 mm
-
AssemblyDIN rail; to be mounted outside the ATEX zone
-
Power supply24 V DC ±5%, 24 V AC ±5%, 230 V AC ±5%
-
Electrical connectionTerminal strip
-
Power consumption max3 VA
-
Recommended cable cross-section2.5 mm²
-
Current and contact load capacity250 VAC, 8 A, 2 kVA
-
Minimum switching capacity10 mA, 5 V DC
-
Ambient temperature-20 ... 50°C
-
CertificatesCE
-
ATEX certificationZone 1, zone 2
-
SIL levelSIL1
-
