Air flow monitor evaluation unit NLSW2a

SKU: 56558

Description

Air flow monitor with switching output for switch cabinet installation

Type tested by TÜV NORD in accordance with DIN EN 61010-1: 2011-07

Large measuring range, quick and easy commissioning

Example areas of application: Monitoring of heating registers, air curtain systems, butterfly valves, fans, DDC


Operating instructions (German/ English)

Power supply
€169,50
Shipping will be charged at checkout.

TÜV type examination: Download

Technical drawing 3D: Download

Technical drawing 2D: Download

Operating instructions EN: Download

Operating instructions EN: Download

Specification
  • Medium
    Gases
  • Flow measuring range
    0.5 ... 30 m/s
  • Media temperature
    -20 ... 80°C
  • Switching point
    Adjustable via potentiometer
  • Enclosure protection class
    IP40
  • Output signal
    Switching output
  • Switching output specification
    Relay output
  • Relay output specification
    Relay output
  • Dimensions
    120 mm x 45 mm x 73 mm
  • Electrical connection
    10 terminals (2.5 mm²)
  • Power consumption max
    3 VA, 4.5 VA
  • Ambient temperature
    -20 ... 50°C
  • Pollution class
    II
