TMS - Thermistor Maschinenschutzrelais für explosionsgeschützte Drehstromventilatoren

SKU: 0157.0992 | Barcode: 4012799579922

Description

✅ Kaltleiterauslösesystem für explosionsgeschützte Drehstromventilatoren zum Einbau in Schaltschränke, zum Überwachen der maximalen Motortemperatur.

✅ Baumusterprüfung gemäß RL 2014/34/EU.

✅ 1 Öffner und 1 Schließer.

✅ Mit Netz- und Fehler-LED-Anzeige und Testtaste.

⚠️ Installation ausschließlich im nicht Ex-gefährdeten Bereich.

€200,00
Shipping will be charged at checkout.
Delivery time symbol Delivery time: Available in 2-3 days

Data sheet DE: Download

Specification
  • Device type
    Accessories
  • Device type
    Compact
  • Enclosure protection class
    IP20
  • Weight
    0,14 kg
  • Dimensions
    104 x 84 x 23 mm
  • Power supply
    24 ... 240 V AC, Drehstrom , 50 Hz / 60 Hz
  • Ambient temperature
    -25°C ... 60°C
  • ATEX certification
    Ex II (2)G [Ex e], Ex II (2)D [Ex t]
