ATEX lamp STRONGEx1 G2/ STRONGEx2 G2, for ATEX zones 1, 21, 2, 22

Sku: 10269625 | Barcode: 4069072074872

Description

✅ Safe and reliable lamp for potentially explosive atmospheres in ATEX zones 1, 21 or 2, 22

✅ Explosion-proof luminaire, Extremely robust and resistant to chemicalssuitable for outdoor use

✅ Highly resistant PMMA profile, Suitable for refineries near the sea with a salty environment

✅ Optional integrated emergency kit with up to 3 hours autonomy

✅ Impact resistance IK10

(HT=high efficiency, EB3=3 hours emergency lighting)

€438,75

Shipment is calculated in the checkout.

Delivery time: Available in 3-4 weeks

Bedienungsanleitung EN: Download

Device type

Stationary light Ex-protected
Protection class housing

IP66
Special features

HT= high efficiency, lower power consumption and higher efficiency, with the same luminous flux
IK impact resistance rating

IK10
Luminous flux

2500 ... 8500 lm, depending on variant
Efficiency

156 ... 181 lm/W, depending on variant
Light color

4000K
Color rendering index CRI

80
Power factor

> 0.95 full load
Weight

2,0 ... 4.0 kg
Dimensions

Length 888 mm at 2800 lm and 3500 lm, Length 1451 mm at 5600 lm and 6000 lm, Length 1732 mm at 7000 lm and 8500 lm
Cable gland

Ex-certified cable gland
Power supply

220 ... 240 V
Electrical connection

3/5-wire terminal strip
Power

16 ... 47 W, depending on variant
Ambient temperature

generally all lamps, min. -20 ... 35°C, -36 ... 55°C, depending on variant
ATEX certification

II 2G Ex eb mb IIC T4 Gb, II 2D Ex tb IIIC T85ºC Db , II 3G Ex ec IIC T6 Gc, II 3D Ex tc IIIC T85ºC Dc
Country of origin

Spain
Warranty

5 years
Service life

L80B50 100,000 h
Manufacturer

Zalux
Emergency light

3 hours: 250 ... 700 lm, depending on variant
